100% Mass Flow meter from China manufacturer - Dalian Metery Technology Co.,Ltd

Price:	200.0~1500.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Liaoning, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: MT100M

Production Capacity: 100PCS/Day

Delivery Date: Ready Stock

Means of Transport: Ocean,Land,Air

Packing: Carton

Brand Name: Metery

1. Accuracy:0.2%; 0.15%; 0.10%;
2. Output signal:4-20mA+0-10KHz+RS485/Hart protocol
3. Material:SS316L Stainless Steel;HC-22

Packaging Detail:	Packaging sponge and carton or according to customer requirements for packaging
Delivery Detail:	50pcs the following month of after confirm the order

Product Description

Main parameter:

Guaranteed 100% high quality air flow meter

The products are serial mass flow. meters,Products size is: DN6, DN10, DN15, DN25, DN40, DN50, DN80 ,and DN100 (units: mm).

Specifications.

Environmental Specifications
Medium	Liquid (include slurry, mixed with solid and so on).
Temperature of environment	0+40
Temperature of medium	-60+200.
Density of medium	0.3 g/cm 33.0g/cm3 Density accuracy ±0.002g/cm3
Pressure on operation	≤4.0Mpa
Atmospheric pressure	86106 Kpa
Humidity of environment	≤90% RH

Sensor of Mass Flow Meter
Type	XYK
Precision grade	0.2
Material of inner tube	316L stainless steel
Join form	Flange or screw.
Explosion proof identification code	Exib[ib]IIBT4 or Exdib[ib]IIBT4.

Transmitter of Mass Flow Meter
Type	XYK-T
Output signal	420mA, 010KHz, RS-485
Power supply.	DC24V or AC220V±10%/50Hz±5%, Power consumed <15W
Form of Explosion-proof .	Essential safety or Composite
Display	Instant flow and gross, temperature, density or concentration and so on.
Batch Control relay.	Contactor capacity: 24V/0.1A Contactor form: normal open ( would be changed to normal close while special order)

We have 0.15 accuracy grade and this is the best one in china. it is 0.1 accuracy grade in international.

Product advantage

1) Using the world's most advanced second generation transmitter technology - DSP technology, higher precision, wider range, more simple structure, more stable operation.

2) Measurement of high pressure gas (such as CNG compressed natural gas (LNG), low temperature liquids such as liquefied natural gas, liquid nitrogen).

3) Using high-precision processing technology, ensure the sensor quality, zero stability.

4) Using digital signal processing (DSP) technology, metering system host through the 485

communication, the relevant parameters, to obtain the required such as: mass flow, volume flow rate,temperature, density, the state information.

5) Through the debugging software or manual debugging device can read the fault code, solving the problem of inconvenient meter using the staff more comprehensive, troubleshooting

6) Support the standard industrial control communication protocol ModbusRTU, easy configuration and use.

7) According to user needs, mass flowmeter in design and manufacture of special specifications and has special function, tailored to the user.

Measuring principle

1) The principle of measuring flow based on rule of Coriolis Motion.

2) After transmitter connecting with sensor, time difference was measured by signal of velocity sensor, then calculate mass flow value by mass circulation calibration coefficient.

3) Transmitter is used to make stream tube resonant, measure mass and density parameters .etc according resonance frequency.

Temperature specification in hazardous zone
